Bilbao s
Air
Forced ventilated air pellet stoves
- Steel
Technical Features
Forced convection pellet stove for warm air production:
- steel structure
- steel cover
- cast iron brazier
- rear smoke outlet
Steel version - Dimensions: 520x540x1040 mm
Introduced power : 9,4 kW
Convection and radiation power output : 8,6 kW
Power performance : 91,7 %
Heatable volume : 120 - 238 m³
Hourly consumption: 0,92 - 1,99 Kg/h
Rated power absorption : 106 W
Tank capacity: 17 Kg
Mimimum stroke: 10 Pa
Smoke outlet diameter: 80 mm
Steel version - Weight: 120 Kg
* All figures are indicatives. Karmek One shall reserve the right to amend models of its production, at any time and without prior notice, in event of product improving.
Colors
- S1000
- S1001
- S1002
Click here and Read the regulations
Download the technical sheet
Download the user's manual
D.m.186 1024 Cs22 0085550 01 Orione 9
EEI label
Ask for information
Download the technical sheet
Download the user's manual
D.m.186 1024 Cs22 0085550 01 Orione 9
EEI label
Ask for information
Discover other stoves of this category Air:
